Product Overview
The Laser Cap is a wearable low-level red-laser device that distributes light across the upper scalp. It is intended for integration into branded scalp-care or hair-growth device programs. The finished indication, treatment protocol, and market claims depend on the regulatory status of the exact final model.
Key Advantages
Defined 650 nm Laser Array
The current configuration has 120 laser diodes at 650 ±8 nm. Each diode is rated at 5 mW, giving a combined nominal output of 600 mW across the complete array.
Even Diode Distribution
The internal holder distributes the 120 diodes around the upper scalp instead of concentrating them in a small central area. On the current holder design, diode position is controlled to a tolerance below 0.1 mm, keeping the planned spacing consistent from unit to unit.
External Type-C Power
The cap uses a Type-C power connection and contains no built-in battery. This reduces the weight carried on the head and keeps the wearable optical assembly separate from the power source.
Key Specifications
|
Parameter |
Value |
|
Wavelength |
650 ±8 nm |
|
Number of lasers |
120 |
|
Power per laser |
5 mW |
|
Total power |
600 mW |
|
Power supply |
Type C (no battery) |
Customization Capabilities
The optical layout can be adjusted for the intended scalp coverage, with diode quantity and spacing coordinated with the internal holder geometry. The shell and holder are developed as one positioning system so the planned distribution remains in place after assembly.
Shell size, ventilation, and the external control connection can be adapted for the wearer interface. Surface finish, labels, instructions, accessories, and packaging can be set for the brand and the agreed market classification.
Quality Control
First-piece approval checks diode placement and the electrical assembly within the holder. During production, visual and manual inspection removes units with misalignment, connection defects, or enclosure damage before final assembly.
Final inspection includes a complete operating cycle to check controller response and stable light activation. Cable retention, enclosure condition, and thermal behavior are verified against the approved product specification.
FAQ
Q: What is the minimum order quantity?
A: The standard MOQ is 10,000 pieces. Approved colors or models may be combined within one order.
Q: How long does custom sample development take?
A: Custom sample development normally takes about 50 days after the optical, electrical, mechanical, and labeling specifications are confirmed.
Q: Is this exact model FDA cleared or CE certified?
A: No clearance or certification should be claimed unless a current certificate or registration identifies this exact model, manufacturer, intended use, and destination market. Regulatory documentation is handled as a model-specific project.
Q: Does a 650 nm wavelength alone guarantee hair-growth results?
A: No. Wavelength is one device parameter. Any hair-growth claim must be supported by the complete optical dose, treatment protocol, device validation, clinical evidence, intended-use labeling, and the authorization required in the destination market.
